1 Watt Carbon Film Resistors

Carbon film resistors are constructed by vacuum depositing a thin, precise carbon film onto a high-grade ceramic core. Designed for high-voltage audio circuits and general electronics, they are an excellent choice for applications requiring a steady, low-power drop, exceptional long-term stability, low noise, and high moisture resistance. Please note that with resistor values, a k or M represents a dot. Eg 5k6 is equivalent to 5.6k or 3m3 is equivalent to 3.3M. If you need help with colours and values, use our Resistor Colour Code Calculator here.

Technical Specifications

  • Power Rating: 1 Watt
  • Working Voltage: 500V
  • Overload Voltage: 1000V
  • Dimensions: 0.5" L x 0.14" Dia. (12.7mm x 3.5mm)
  • Features: High stability, low noise, moisture resistant
  • Identification: Standard EIA color coded

Available Resistance Values

Retail quantities only – Max. 25 per value

Ohms (Ω / R)

1R10r22r27r39r47r56r68r100r120r150r180r220r270r330r390r470r560r680r820r

Kilohms (kΩ)

1k01k21k51k82k22k73k33k94k75k66k88k210k12k15k18k22k27k33k39k47k56k68k82k100k120k150k180k270k330k390k470k560k680k820k

Megohms (MΩ)

1m01m21m51m82m22m73m34m75m66m810m
SKU M-1wattcarbon
Brand Generic
Shipping Weight 0.0001kg
Shipping Width 0.010m
Shipping Height 0.050m
Shipping Length 0.060m
Shipping Cubic 0.000010000m3
